I have a selection of chassis on hand and I just weighed and measured them. Here's what I got:
Gold A light anodize: 6.0oz/1.4mm thickness
Gold A dark anodize: 5.7oz/1.4mm thickness
Gold B: 5.9oz/1.4mm thickness
Black B: 5.7oz/1.4mm thickness
40th: 5.7oz./1.4mm thickness
Sorry for the mix of oz. and mm....I only had a postal scale on hand.
I should have noted that I originally only took one thickness measurement of each...across the FLAT area where the rear arms attach, as another poster had suggested. But now I've taken three measurements on each and all five chassis are ALL still 1.4mm. All three places I measured each are FLAT areas of the chassis that are not subject to deformation or have an irregular edge....which every RC10 chassis I've ever seen has along the top side edge, which prevents a caliper from getting a true reading of the thickness. The actually FLAT areas that were measured were:
Across the rear chassis at the rear arm mount
At the front vertical edge just below where the front support tubes attach
At the very front bottom of the chassis where the nose plate attaches
Here's my evidence.....er...I mean pics:
Re: RC10 Classic 40th anniversary
Posted: Wed May 29, 2024 12:16 am
by azone
ok, I think it's good to have reference points. For my data I will take those additional measurements and add them to my post. If I scratch one of my chassis with the calipers I'm blaming you guys! If we can get one or two more people would be cool too, even if just one chassis version on hand...
Re: RC10 Classic 40th anniversary
Posted: Wed May 29, 2024 1:17 am
by RogueIV
azone wrote: ↑Tue May 28, 2024 8:37 pm
NeonNoodle wrote: ↑Tue May 28, 2024 12:57 pm
XLR8 wrote: ↑Mon May 27, 2024 10:28 pm
RogueIV wrote: ↑Mon May 27, 2024 9:18 pm
morrisey0 wrote: ↑Mon May 27, 2024 7:54 pm
Do you have actual thickness numbers to support the thinner claim? From my research, I have heard the 40th is as thick as an original variant. I haven't opened my 40th, so I can't confirm.
I have personally confirmed that it's the same thickness as a B stamp chassis. I'm not sure where people keep coming up that it is thinner and have not seen any proof as such.
I've just measured the tub on my 40th and it measures same as one of my early A stamp chassis tubs. Both tubs were measured in the same place; the flat area behind the rear arm mounts under the motor.
I have a selection of chassis on hand and I just weighed and measured them. Here's what I got:
Gold A light anodize: 6.0oz/1.4mm thickness
Gold A dark anodize: 5.7oz/1.4mm thickness
Gold B: 5.9oz/1.4mm thickness
Black B: 5.7oz/1.4mm thickness
40th: 5.7oz./1.4mm thickness
Sorry for the mix of oz. and mm....I only had a postal scale on hand.
Nice! I'll add my measurement here. Maybe others can add as well. I
did find a variation between the old and the new. The original is likely 14 gauge 6061-T6 aluminum. The median thickness should be 1.63mm, but as someone who owns a manufacturing company and deals with CRS and aluminum the variation in stock can be great depending on lots and where it is manufactured. There is also a lot of secondary processes on the RC10 chassis that will deform the dimensions so I took measurements in three different places for each chassis. Also. the upper edge of the chassis can have a lip (especially the CC/40th) so in any areas there was a lip, I placed the calipers below this area for a more accurate measurement.
Gold A light anodize: 1.74/1.70/1.64. Average 1.69mm thickness.
Gold B dark anodize: 1.53/1.72/1.70. Average 1.65mm thickness.
Gold 40th: 1.50 / 1.53 / 1.51. Average 1.51mm thickness.
RC10CC: 1.44 / 1.43 / 1.46. Average 1.44mm thickness.
I have not weighed the old gold pans unfortunately as I don't want to take them apart. From holding them and feeling them side by side though the 40th and CC chassis feel like a tin can next to the old ones. I would argue the newer ones are 16 gauge aluminum (and not sure what alloy/grade).
To really know what stock they used you really should be measuring from the bottom of the pan like where the trans mounts as the side are stretched on a form so the thickness will vary a lot more on those locations.
Edit: i missed the last update oops
Re: RC10 Classic 40th anniversary
Posted: Wed May 29, 2024 4:06 am
by BattleTrak
Here is a no stamp chassis…slightly thicker @ 1.67mm.
Re: RC10 Classic 40th anniversary
Posted: Thu May 30, 2024 3:47 pm
by azone
BattleTrak wrote: ↑Wed May 29, 2024 4:06 am
Here is a no stamp chassis…slightly thicker @ 1.67mm.
so is that a very early chassis? that's pretty cool.
Make sure to check out my earlier post on page 27, I spent
way too much time and added some more data and a video link. In the case of mine I found my vintage chassis are stiffer, slightly thicker, and heavier.
